Introduction to Maserati
Electric and Electronic Systems
IT NODE (NIT)
The IT Info Node is an ECU located in the centre of the dashboard which integrates informative, IT, audio/ video and air conditioning and heating system programming functions. The NIT has a multifunction display and a series of controls for interaction connected to the main electronic unit. The IT Node - NIT- performs the following functions: •
It receives and transmits information via B-CAN line (e.g.: diagnosis, data)
•
It incorporates the menu interaction controls
•
It manages a high definition colour display for varied information and navigation or the TV
•
It interconnects with the dashboard wiring for the connection to the vehicle’s electric system
•
It interconnects with the IT wiring for the point-to-point connection with the TV tuner, CD changer
•
It interfaces with the GPS, GSM and radio aerials by means of coaxial cables
•
Vehicle setup
N.B: The telephone module (opt.) is fitted separately underneath the Silver Box.
Maserati Academy
407
