Robotized Gearbox
ROBOTIZED GEARBOX CONTROL SYSTEM The robotized gearbox control system is composed of an electro-hydraulic servo system which manages the gearchange and clutch operation. A specific ECU (NCR) controls the complete system by using a strategy which is based on driver inputs and various vehicle parameters. Therefore the NCR interacts with other vehicle systems (NCM, NFR,…) and uses a driver interface (gearshift paddles and control buttons). A specific characteristic of the system is that it can be integrated on a mechanical transmission without requiring any specific modifications.
1
Robotized gearbox layout
2 4 3 6
5
4
1.
Clutch Pressure Sensor on Clutch Housing (Sofast III onward)
2.
Gearbox Unit
3.
Hydraulic actuator
4.
Accumulator
5.
Reservoir
6.
Power Unit Assy
2 Robotized gearbox layout
3
1
Display
w
Hydraulic actuator
w
Solenoid valves
w
Power unit
w
Accumulator
Driver controls: Steering wheel gearshift paddles assy. Reverse button
•
Display
•
Steering wheel gearshift paddles
•
Reverse gear selection
•
Auto/manual mode selection
"Race" button
