Body Builder Connections LR Control Link II The body builder connector can be accessed by removing the panels on the center console. The suggested routing path for upfitters is not a physical component provided with the vehicle. It’s purpose in the illustration is to indicate the suggested wiring routes for upfitter harnesses. For convenience, MACK provides a pair of rubber grommets located behind the driver seat. This is the pass-through area which leads beneath the cab.
W9096945
1 29-pin Body Builder Connector 2 9-pin Lighting Connector 3 Suggested Harness Routing for Upfitters
Mack Body Builder Instructions USA139388593
CHU, CXU, GU, TD, MRU, LR Date 7.2017
Electrical Wiring and Connections
Page 39 (94) All Rights Reserved
