Ring Terminal Assembly Assemble terminal carrying the highest current (largest gauge wire) first, then graduate to the smallest gauge up to the fastener. Use a maximum of three (3) terminals per stud (unless otherwise specified on an illustration drawing).
W3104152
When attaching ring terminals with a fastener, tighten the fastener to appropriate torque so that the contact area will touch the terminal at any point, in a full circle that is part of the terminal.
W3104153
1 Contact Area 2 Fastener 3 Stud 4 Terminals
Mack Body Builder Instructions USA139388593
CHU, CXU, GU, TD, MRU, LR Date 7.2017
Electrical Wiring and Connections
Page 14 (94) All Rights Reserved
