LUBRICATION
TRAVEL REDUCTION GEARS Service specifications Oil level check ............................................................................... Every 250 hours Oil change ................................................................................... Every 1000 hours (after the first 250 hours of operation) Oil capacity (per reduction gear) ...................................................... 1.2 gal (4.7 L) Oil type .................................................................................................API GL-4 90
Level
STEP 4
STEP 1 Park the machine on flat, horizontal ground.
2
STEP 2
TRIM THIS EDGE
BD01E055
1
Remove the plug (2) and check the oil level. The level must come up to the lower edge of the hole. If necessary, add oil through hole until the level comes up to the bottom edge of the hole.
BD01E055
Move the machine so that plug (1) is in the lowest possible position. STEP 3
STEP 5 Install plug (2) . STEP 6
Stop the engine and remove the starter switch key.
Repeat Steps 2 to 5 for the other travel reduction gear. STEP 7 Travel slowly with the machine and make sure there are no leaks.
166
