LUBRICATION
SWING REDUCTION GEAR Service specifications Oil level check ............................................................................... Every 250 hours Oil change ................................................................................... Every 1000 hours (after the first 250 hours of operation) Grease ........................................................................................ Every 5000 hours Oil capacity ....................................................................................... 1.6 gal (6.0 L) Oil type .................................................................................................API GL-4 90
Level
STEP 3
STEP 1
Install the dipstick
Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key.
Draining and refilling
STEP 2
STEP 1
TRIM THIS EDGE
Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key.
1
STEP 2
BD01G037
BD01G037
Remove the dipstick and the filler plug. STEP 3
CP98N043
Remove the dipstick. The oil should come up to the hatched area. Add oil if necessary through the filler hole (1).
164
