Control and operation
Operating manual
Operating and control elements
Symbol
Description Confirm service interval
Select quantity limitation relating to attachments (eg. hammer)
Operating hours and device data
Status of hydraulic pumps and electrical inputs and outputs
Recorded and stored errors
Immobilizer (must be activated by LIEBHERR customer service using a service connector) Tab. 3-1
Overview of menu options
Reset daily operating hours counter menu The daily operating hours counter can be reset to 0 using this menu.
Fig. 3-12
Resetting the daily operating hours counter
To set the daily operating hours counter to 0: Press the Up arrow key. The OK which is not crossed out will be displayed with a black background.
To exit the menu: Press the Back button. The submenu will be canceled.
Confirm service interval menu This menu is used for information on service intervals and to confirm service work which has been carried out.
3 - 18
copyright © Liebherr-Mining Equipment Colmar SAS 2020
MJFCIFSS
R 9250 E / 10360689
LEC/en/Edition: 12 / 2020
Press the Menu* button. The operating hours will be reset to 0. The arrow key symbols Up and Down and the Menu symbol will no longer be displayed.
