Control and operation
Operating Manual
Operating and control elements
The related numerical value is also shown under the dial needle. If a measured value is out of the possible range (e.g. in case of defective sensor):
In this case, contact Liebherr customer service. If the signal transmitting communication is broken:
NO SIGNAL!" -50" for standard values (e.g. temperature, pressure) -1" for strictly positive values (e.g. percentage, speed) In this case, contact Liebherr customer service. Error warning symbols The error warning symbols can be shown anywhere in the central field 2. If all the symbol locations are on, the system show the most important symbols. If the same error occurs on different elements, the error symbol is on and the different related parameters flash alternatively. For errors description, refer to the section "Indicator and error warning symbols".
Camera views The main screen has two windows, which show the image from the monitoring cameras. Push the "Main screen" button to go back to the camera views from all others menus.
Buzzer and links field
Fig. 3-11 3
Links field
Buzzer and links field
With the lower field 3, you can get access to different functions.
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 14
MJFCIFSS
R 9150 E / 12242219
