Control and operation
Operating Manual
Working with the machine
turer: Quick coupler" is located on the A170 keypad.
Fig. 3-83
Confirmation button S497 is located on the cab control board.
Control of the hydraulic hammer (optional) Install the hydraulic hammer. Refer to the section "Attaching and dismounting equipments parts" of this manual. Danger! Additional operating and control elements (joysticks/pedals) can have different functions. Always check functions of operating and control elements when you start a machine which has an additional attachment. For safety instructions, also turer. For use and control, also refer to the O You can control the hammer with the pedal or with the joystick.
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 104
MJFCIFSS
R 9150 E / 12242219
