Control and operation
Operating Manual
Working with the machine
Shake the bucket (with backhoe attachment only) You can shake the bucket to remove dirt collected in the backhoe bucket. Operate very quickly the right joystick 3 as follows:
While you do this sequence, the bucket shakes. Caution! Repetitive shakings cause fast wear of the components.
Operating the bottom dump bucket for shovel attachment Danger! Additional operating and control elements (joysticks/pedals) can have different functions. Always check functions of operating and control elements when you start a machine which has an additional attachment.
Manual flap control If the selection function is installed, you can control the bottom dump shovel bucket with the pedal or with the joystick.
Fig. 3-78
Rotary switch for control selection (if installed)
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 100
MJFCIFSS
R 9150 E / 12242219
