Control and operation
Operating Manual
Setting the machine into operation
wise on approximately 1/2 turn. Repeat 4 times in each direction. Step 3 - Repeat step 2 a second time. Step 4 - Repeat step 2, with reaching end position of piston rod. Step 5 - Repeat step 4 a second time. Step 6 - Check oil temperature in hydraulic tank. If oil temperature is under 10°C, repeat step 4 until oil temperature reaches 10°C. If oil temperature is above 10°C, move to step 7. The step 7 that follows is applicable only to crawler excavators. Step 7 - Start the travel hydraulic circuits very slowly forward and backward on approximately 10 meters. Repeat 4 times. The excavator can now be operated.
3.3.3
Emergency and safety operations Emergency stop Location of the emergency stop buttons Different emergency stop buttons are installed on the machine.
Fig. 3-60
Cab emergency stop S100_1
The emergency stop S100_1 is located on the cab control board.
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 78
MJFCIFSS
R 9150 E / 12242219
