Control and operation
Operating Manual
The access and the outfit of the cab
Danger! Never actuate the sliding access ladder if you or a third person are on the ladder or in immediate proximity of the ladder. Move the ladder into lower position from the uppercarriage Manually lift the ladder 1 and push the lever 2 with your foot to unlock the ladder. Lower the ladder 1 to the stop. Move the ladder into lower position from the ground Manually lift the ladder 1 and push the lever 3 with your hand to unlock the ladder. Lower the ladder 1 to the stop. Move the ladder into upper position (working position) Lift the ladder 1 to the stop. Caution! For safety reason, the excavator can only be operated if the ladder is locked in its top position. This means that the swing and travel movements remain locked. This safety measure can be momentarily by-passed by pushing and holding the button S122 on the control board.
Fig. 3-20
Button S122: Disable of ladder control position
45° access ladder (optional) An optional 45° access ladder can be installed on the excavator. It is automatically
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 38
MJFCIFSS
R 9150 E / 12242219
