Control and operation
Operating Manual
Operating and control elements
Solenoid valve of swing right (status light)
Pedal for special and/or optional controls (if installed)
Adjustment solenoid valve of swing left
Joysticks left (L) and right (R) movements in all directions
Adjustment solenoid valve of swing right
Uppercarriage swing
Last page
Analog stick for special and/ or optional controls (if installed)
Submenu "Tool control" (optional) This optional submenu is available when you can install special tools on the machine. Thus, when you connect a tool, you must use this submenu to select its related parameters (tool type, operating flows and pressures). These parameters are set by a Liebherr service personnel.
Caution! Risk of damage! Incorrect setting of the operating flow and/or pressure can cause damage to the attachment or limited operation of the attachment. Do the related procedure to select the correct parameters for the tool that you will install. Refer to the section "Attaching and dismounting equipment parts" of this manual.
Highlight for the parameters selection
Selected parameters
When you select a tool, a special message is also shown in the menu "Diag". To use this submenu, refer to the section "Attaching and dismounting equipment parts".
