Malfunctions
Operating Manual
Fuses and relays
Electrical plate A1002
Fig. 4-7
Fuses and relays of electrical plate A1002
F40 F41
Fuse 15 A / Rear lights top of cab F69 Fuse 15 A / Camera light electri- F70 cal boxes S1 and S2
Fuse 15 A Fuse 15 A
F42
Fuse 15 A / Camera light counter- F71 weight Fuse 15 A / Light electrical boxes F72 S1 and S2
Fuse 15 A
F44
Fuse 15 A / Light counterweight
F73
Fuse 15 A
F45 F46
Fuse 5 A Fuse 5 A / Y6 and Y7
F74 F75
Fuse 15 A Fuse 5 A / P5
F47 F48
Fuse 15 A Fuse 15 A
F76 F77
Fuse 10 A Fuse 10 A
F49 F50
Fuse 15 A / Supply A54 Fuse 15 A / Supply A54
F78 K15
Fuse 5 A / Buzzer Relay / Rear lights top of cab
F51
Fuse 15 A / Supply A54
K16
Relay / Camera lights electrical boxes S1 and S2 and counterweight
F52 F53
Fuse 15 A / Supply A54 Fuse 5 A / E70 reading lamp
K17 K18
Relay / Front lights top of cab Relay / Light electrical boxes S1 and S2
F54
Fuse 5 A / R94 side mirror
K19
Relay / Light counterweight
F55
Fuse 15 A / Supply A1002
K20
Relay
F56
Fuse 15 A / Supply A54
K21
Relay / Y6 and Y7
F43
Fuse 15 A
copyright © Liebherr-Mining Equipment Colmar SAS 2020
4 - 12
MJFCIFSS
R 9150 E / 12242219
