Control and operation
Operating Manual
General working methods
Fig. 3-118 Transporting a load Transport the load close to the chassis, but with sufficient safety distance to the cab (swinging grab!) and as close to the ground as possible. Caution! Particularly when loading wood, it can be necessary when working with a grab to move with the working equipment raised and the load taken up. This will shift the centre of gravity of the machine upwards. The way the machine drives will be negatively affected because of this. these operating instructions.
3.6.10
Skimming Skimming work can either be carried out using the bucket or with a skimming shield (optional extra).
Fig. 3-119 Skimming The machine must be in the working position. The support should be raised.
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 134
MJFCIFSS
R 9150 E / 12242219
