Working with the machine
Hammer control with the analog stick Make sure that the related mode is selected with the rotary switch S256.
Fig. 3-86
Hammer control with the analog stick
Push the analog stick on the right joystick 3 to the left 7c. Hydraulic hammer is activated. The activation of the analog stick to the right is not used.
Control of the grapple / shear (optional) Install the grapple / shear. Refer to the section "Attaching and dismounting equipments parts" of this manual. Danger! Additional operating and control elements (joysticks/pedals) can have different functions. Always check functions of operating and control elements when you start a machine which has an additional attachment. For safety instructions, also turer. For use and control, also refer to the Oper
