Control and operation
Operating Manual
The access and the outfit of the cab
Front working lights and attachment headlights Push the button. Front working lights on the uppercarriage are activated. First LED in the button comes on. Push the button again. Front working lights and attachment headlights are activated. First LED and second LED in the button are on. Push the button a third time. Front working lights are deactivated. First LED in the button goes off. Attachment headlights remain activated. Second LED in the button is still on. Push the button a fourth time. Attachment headlights are deactivated. Second LED in the button goes off.
Rear working lights Push the button. Rear top of cab working lights are activated. First LED in the button comes on. Push the button again. Rear counterweight working lights are activated. First LED and second LED in the button are on. Push the button a third time. Rear top of cab working lights are deactivated. First LED in the button goes off. Push the button a fourth time. Rear counterweight working lights are deactivated. Second LED in the button goes off.
