Control and operation
Operating Manual
Operating and control elements
Incorrect deactivation procedure This symbol is shown if you push at the same time "Overload warning device" and S497 buttons. The overload warning device continues to operate. The deactivation procedure is cancelled after 5 seconds. Quick coupler (optional) Find all information and details in the Operating Manual of the quick coupler manufacturer. Activation waiting time This symbol is shown while the system waits the activation of the quick coupler.
Activation of the system These two symbols are shown at the same time while the activation of the quick coupler is confirmed. Unlocking This symbol is shown during the unlocking procedure of the quick coupler.
Locking This symbol is shown during the locking procedure of the quick coupler.
Unlocking warning symbol This symbol is shown when the quick coupler is unlocked. In this case, you can hear a warning signal. Working tool warning symbol This symbol is shown if none tool is sensed by the system. In this case, you can hear a warning signal. Incorrect activation procedure This symbol is shown if the activation procedure is done incorrectly.
Other error symbols (6) The other error symbols show other malfunctions of the machine in the field 6. These symbols have the same structure as above. Three symbols can be shown in the field 6. The most important symbol is shown in higher location. The less important symbol is shown in lower location. If the same error occurs on different indexed elements, the error symbol is on and the different index flash alternatively. If all the error symbol locations are on, the system show the most important symbols.
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 32
MJFCIFSS
R 9150 E / 12242219
