Control and operation
Operating Manual
Operating and control elements
2
Other errors symbols
3
Electric motor error symbols For symbols description, refer to the sections that follow.
General indicator symbols (1) The indicator symbols give information about the conditions and the setting of the machine. They are related to functions activated with the keyboard. Travel brake closed This symbol is shown if the Travel brake button has been pressed on the control keyboard. Swing brake closed This symbol is shown if the Swing brake button has been pressed on the control keyboard. Swing brake closed during uppercarriage swing movement This symbol is shown if the Swing brake button has been pressed on the control keyboard while the uppercarriage turns. A buzzer is activated in the cab. Brakes manu This symbol is shown if the Safety Brake Control has been allowed through emergency functions. Power Control off This symbol is shown if the Power Control Manu has been allowed via emergency functions. Flow Control off This symbol is shown if the Flow Control Manu has been allowed via emergency functions. Fan Control off This symbol is shown if the Fan Control off has been allowed via emergency functions. Speed Control off This symbol is shown if the Speed Control Manu has been allowed via emergency functions. No function
Shovel movement blocked This symbol is shown if the shovel movement is blocked (when grease level is low or when the track tensioning procedure is in progress).
