Control and operation
Operating Manual
Operating and control elements
Fig. 3-16
Submenus of the menu "Settings"
Submenus: This submenu is used to set the time.
Time
Wiper
This submenu is used to set the windscreen wiper interval.
Brightness
This submenu is used to set the luminescence of the display.
Language
This submenu is used to set the language in which the error codes are written.
Set a parameter From each submenu of the menu "Settings": Push the safety lever up.
Push the "Up" and "Down" buttons to select the parameter to set (time, value or language).
Push the "Accept" button to record the new parameter.
Submenu "Time"
You can also use this submenu to switch from summer to winter time (and back again). Push the "Daylight" button. This symbol is transparent when the time difference of an additional hour is deactivated. This symbol is green when it is activated. Submenu "Brightness"
copyright © Liebherr-Mining Equipment Colmar SAS 2020
3 - 28
MJFCIFSS
R 9150 E / 12242219
