Assembly process No.
M-6
Replacement of return filter (Replacement of standard filter → special flushing parts) (1/2)
1. Replace the element of hydraulic oil return filter with exclusive flushing element (1), and replace valve and strainer with plate (2). a When replacing the elements, take out the element slowly so that refuses adhered to the element do not fall inside. Also, take out refuses by hand from the case. a Confirm the installing condition of the element in accordance with "2. Installing Condition of Element". a When the atmospheric temperature is below –15°C, do not use (2). Replace only the element and flush the circuit while running the engine at low idle.
No. 1 2
Part Name Element Plate
Part No. 208-60-71170 21T-60-13730
Q'ty 1 1
Exclusive flushing element
a Removed standard element (208-60-71123), strainer (07069-25400) and valve (208-60-71160) will be used again after flushing is finished. Accordingly, clean and keep them so that they will not be damaged.
167
