JLG 30E 35E N35E 40E N40E 45E Parts Manual (3120744) - PDF DOWNLOAD (Eng)

Page 206

SECTION 9 - RECOMMENDED SERVICE PARTS STOCK FIGURE 9-1. 30/35/40/45 ELECTRIC LIFTS STANDARD PARTS

ITEM

206

PART NUMBER Note

QTY Ref

3990053 3990053 3990053 2400045 2400045 2400045 4360371 4360371 4360371 2120072 2120072 2120072 7013709 7013709 7013709 7010538 7010538 7010538 4360473 4360473 4360473 2860030 2860030 2860030 4360069 4360069 4360069 4360475 4360475 4360475 4360314 4360314 4360314 4360476 4360476 4360476 4360031 4360031 4360031 4360445 4360445 4360445

Ref 1 1 1 2 2 2 1 1 1 4 8 12 1 2 3 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

DESCRIPTION Note: The following list will service fleets of machines (built to current production per date on the front cover) with emergency repair parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department. STANDARD PARTS Sensor, Tach, (for fleets of 1 to 4) Sensor, Tach, (for fleets of 5 to 9) Sensor, Tach, (for fleets of 10 or more) Fuse, (for fleets of 1 to 4) Fuse, (for fleets of 5 to 9) Fuse, (for fleets of 10 or more) Sensor, Level, (for fleets of 1 to 4) Sensor, Level, (for fleets of 5 to 9) Sensor, Level, (for fleets of 10 or more) Element, Hydraulic Filter, (for fleets of 1 to 4) Element, Hydraulic Filter, (for fleets of 5 to 9) Element, Hydraulic Filter, (for fleets of 10 or more) Breather/ Dipstick Assembly, (for fleets of 1 to 4) Breather/ Dipstick Assembly, (for fleets of 5 to 9) Breather/ Dipstick Assembly, (for fleets of 10 or more) Coil, (for fleets of 1 to 4) Coil, (for fleets of 5 to 9) Coil, (for fleets of 10 or more) Switch, Key, (for fleets of 1 to 4) Switch, Key, (for fleets of 5 to 9) Switch, Key, (for fleets of 10 or more) Key, Replacement, (for fleets of 1 to 4) Key, Replacement, (for fleets of 5 to 9) Key, Replacement, (for fleets of 10 or more) Breaker, Circuit - 10 Amp, (for fleets of 1 to 4) Breaker, Circuit - 10 Amp, (for fleets of 5 to 9) Breaker, Circuit - 10 Amp, (for fleets of 10 or more) Switch, Emergency Stop, (for fleets of 1 to 4) Switch, Emergency Stop, (for fleets of 5 to 9) Switch, Emergency Stop, (for fleets of 10 or more) Switch, Toggle, (for fleets of 1 to 4) Switch, Toggle, (for fleets of 5 to 9) Switch, Toggle, (for fleets of 10 or more) Contact Block, (for fleets of 1 to 4) Contact Block, (for fleets of 5 to 9) Contact Block, (for fleets of 10 or more) Footswitch, (for fleets of 1 to 4) Footswitch, (for fleets of 5 to 9) Footswitch, (for fleets of 10 or more) Potentiometer, (for fleets of 1 to 4) Potentiometer, (for fleets of 5 to 9) Potentiometer, (for fleets of 10 or more)

30e/35e/n35e/40e/n40e/45e

REV

3120744
