FIGURE 1-1. FRAME AND STEERING INSTALLATION - MODEL 30ELECTRIC
ITEM PART NUMBER QTY DESCRIPTION REV
Ref FRAME WELDMENT OPTIONS: 2360378 1 Frame Weldment Ref STEERING AND SPINDLES INSTALLATION 0252243 Ref Steering and Spindles Installation (Prior to SN 0300052767) 8 0270291 Ref Steering and Spindles Installation (SN 0300052767 to Present) 2 1 1001139010 2 Hub Assembly (Includes Items 101-107) (was p/n 2780186) Ref Note: Original Equipment Hub p/n 2780186 uses Wheel
Bolts. Service Replacement Hub p/n 1001139010 uses pressed in studs - Lugnuts p/n 3300255 must be ordered separately.
2 4130286 2 Spindle Weldment (Includes Items 201-205) 3 3421988 2 Kingpin 4 3450810 2 Pin, Cotter 1/4in x 2 1/2in 5 3313003 2 Nut, Slotted 1 1/4in - 7NC 6 0440162 2 Washer, Thrust 7 0642016 2 Bolt 5/8in-16NC x 2in 8 3312005 2 Locknut 5/8in-16NC 9 3841146 2 Rod-End 10 3322002 2 Nut, Jam 5/8in-16NC 11 Ref Steer Cylinder Assembly (See CYLINDER SECTION for Breakdown) 11 1682527 1 Steer Cylinder Assembly (Prior to SN 37950) 11 1683695 1 Steer Cylinder Assembly (SN 37950 to Present) 12 3340644 1 Pad, Wear 13 0641510 2 Bolt 5/16in-18NC x 1 1/4in 14 3311505 2 Locknut 5/16in-18NC 15 4751500 4 Flatwasher 5/16in 16 3020022 AR Grease 17 4070809 AR Shim 18 3780182 4 O-Ring 19 See Note 10 Bolt, Wheel (Note: Refer to Item 107) 20 0641608 2 Bolt 3/8in-16NC x 1 (SN 0300052767 through 0300053809) 21 4740453 2 Flatwasher 3/8 (SN 0300052767 through 0300053809) 22 0182002 1 Angle (SN 0300052767 through 0300053809) 23 0182000 1 Angle (SN 0300052767 through 0300053809) 24 0641514 2 Bolt 5/16in-18NC x 1 3/4 (SN 0300052767 through 0300053809) 25 0100019 AR Loctite (Not Shown) (SN 0300052767 through 0300053809) 26 4711600 2 Flatwasher 3/8in (Narrow) (SN 0300052767 through
0300053809)
2780186 Ref HUB ASSEMBLY (ORIGINAL EQUIPMENT) C
1001139010 Ref HUB ASSEMBLY (SERVICE REPLACEMENT) Ref Note: Original Equipment Hub p/n 2780186 uses Wheel Bolts.
Service Replacement Hub p/n 1001139010 uses pressed in studs - Lugnuts p/n 3300255 must be ordered separately.
101 7012519 2 Cup, Bearing - Inner (1 Per Hub) 102 7012520 2 Cone, Bearing - Inner (1 Per Hub) 103 7012521 2 Cup, Bearing - Outer (1 Per Hub) 104 7012522 2 Cone, Bearing - Outer (1 Per Hub) 105 7012523 2 Seal (1 Per Hub) 106 1001102354 2 Cap, Dust (1 Per Hub) (was p/n 7012524) 107 0630016 10 Bolt, Wheel (5 Per Hub) (was p/n 7012525) (Used on Original A
ITEM PART NUMBER QTY
DESCRIPTION
Equipment Hub p/n 2780186) 107 7016360 10 Stud, Wheel (5 Per Hub) (Used on Service Replacement Hub p/n 1001139010) (Not Shown) 107 3300255 10 Lugnut (5 Per Hub) (Used with Service Replacement Hub p/n 1001139010 - Must be purchased separately) (Not Shown) 2900804 2 Bearing and Seal Kit (Includes Qty 1 of Items 101-105) 4130286 Ref SPINDLE WELDMENT 201 0961621 4 Bushing, Bronze (2 Per Spindle) 203 7012542 2 Washer (1 Per Spindle) 204 7012541 2 Nut, Slotted (1 Per Spindle) 205 7012543 2 Pin, Cotter (1 Per Spindle)
