SSM60 & SSM72 (SZ330) e. The label showing the relationships between the setting holes and cutting heights is stuck on the mower deck.
８６５４−９０１−０９１−０
f. The right and left gauge wheels should be set to the same cutting height.
Ａ Ｃ Ｅ Ｇ
Ｂ Ｄ Ｆ
Ａ Ｃ Ｅ Ｇ
g. Shift the lift lever to down position ( mower deck.
Ｂ Ｄ Ｆ Ｈ
) to lower the ｉｎｃｈ（ｍｍ）
CAUTION: Before operating the lift lever, be seated in the operator's seat and make sure of the safety conditions when lowering the mower deck.
3. STARTING MOWING OPERATION
４．５（１１５）
Ａ
４．０（１０２）
Ｂ
３．５（８９）
Ｃ
３．０（７６）
Ｄ
２．５（６３）
Ｅ
２．０（５０）
Ｆ
１．５（３７）
Ｇ
１．０（２５）
Ｇ
ＳＬＩＤＥ
Ｈ
FIG. 95
a. Start the engine and shift the throttle lever,1, to the intermediate position between the low speed ( ) and high speed ( ) positions. b. Shift the lift lever,2, to up position ( mower deck.
) to raise the
3
c. Release the parking brake. 25
d. Push the drive control lever gradually to drive the Zero turn mower into the working site. CAUTION: Before starting to move the zero turn mower, be sure to lock the rear gauge wheels either in vertical or slanted positions. e. Release the drive control lever gradually to stop the zero turn mower. f. Shift the lift lever to down position ( mower on the ground.
1
) to lower the
FIG. 96 (1) Throttle lever
g. Turn the PTO switch,3, to the ON (
2
) position.
IMPORTANT: • To engage PTO, first turn switch clockwise and then pull up it. • When engaging the PTO clutch, slow down the engine speed sufficiently for safety. CAUTION: Whenever you encounter with any trouble of the mower, ask your dealer for repair immediately.
84
(2) Lift lever
(3) PTO switch
