CHAPTER 3. ATTACHING AND DETACHING MOWER DECK WARNING: When attaching or detaching the mower deck to the zero turn mower: • Place the zero turn mower on level, hard ground. • Apply the parking brake securely. • Turn the PTO switch to the OFF ( ) position. • Do not start the engine except for operating the lift.
position (25 mm). d. Align the mower deck,4, to along side with the Zero turn mower. Turn its rear gauge wheels,5, by 90 degrees. e. Set the front gauge wheels,6, to the minimum trimming height. f. Slide the mower deck,4, under the mower and position the deck to be at the center of the mower.
1. ATTACHING THE MOWER DECK a. Start the engine and slightly drive the mower backwards. Make sure that the front wheel casters,3, are in the reverse direction. Step on the brake pedal,9, and lock the parking lever,10. b. Shift the lift lever,1, to up position ( ) to raise the lift link,2, to highest level. Then stop the engine. c. Set the height adjust dial,7, to the minimum trimming
7 1 11
9
10
8
12 5
8
4
2
6
3
FIG. 89 (1) Lift lever (2) Lift link (3) Front wheel caster
(4) Mower deck (5) Rear gauge wheel (6) Front gauge wheel
(7) Height adjust dial (8) Link pin (9) Brake pedal
80
(10) Parking lever (11) Drive shaft (12) Adjust shaft
