SZ330
CHAPTER 8. MAINTENANCE What are explained hereunder are the maintenance items which you can cope with. When you encounter any abnormality or trouble which is not mentioned in this manual, please ask your dealer for service. WARNING: When lubrication or servicing the Zero turn mower: • Place it on level, hard ground. • Stop the engine and remove the starter key. • Depress the brake pedal and lock the parking brake securely. • Shift the lift lever to down position ( ) to lower the mower deck onto the ground. • Shift the PTO switch to the OFF position ( ). • Service the Zero turn mower after the engine has cooled down sufficiently. With these items in mind, confirm the safety conditions for maintenance operation without fail ahead of time.
1
FIG. 46
Service access
2 Opening / Closing hood To release the hood, move the open/close level1, in the direction shown by the arrow.
FIG. 47
Open the hood by grasping and lifting up the front of the food. Folding seat and suspension forward To fold seat and suspension forward, remove the bolts, 2, and then grasp the backrest of the seat and fold seat and suspension forward.
3 NOTE: In case of folding the seat only forward, firstly move the plate,3, rearward. Then grasp the backrest of the seat and fold the seat forward. FIG. 48
FIG. 49 46
