TLE3410 INSTRUMENT PANEL FIG. 36: Gauges, control switches and indicators are located in instrument panel. Items are as follows:
3
1. Main Switch 2. Indicator Light Array 3. Tachometer 4. Engine Hourmeter 5. Fuel Gauge 6. Horn Switch 7. Headlamp Switch 8. Direction Indicator Lamp Control 9. DPF Regeneration Inhibit Switch 10. DPF Manual Regeneration Switch 11. Hazard Warning Lamp Switch 12. PTO switch
2
5
4 9 10
8 7
6
11 FIG. 36
Main Switch FIG. 37: Main Switch (1) has the following 3 positions: OFF....... Tractor engine and all electrical circuits off.(except for headlamp, position lamp, rear registration plate lamp and hazard warning lamp) Turning main switch to OFF position will stop engine. Key can be removed. ON........ Power supplied to all circuits. Normal operating position. FIG. 37 START... Starter activated. This position is spring located to “ON” position. NOTE: The main switch must be turned to “ON” position before any circuits will operate. The PTO switch must be OFF, Parking Brake Lever must be set and, for HST Type, Range Shift Lever and HST Pedal are set at neutral position or for Mechanical Type, Range Shift Lever, Forward / Reverse Lever and Clutch Pedal are set at neutral position, before the engine can be started.
