PTO Operating Control (S-Type and HST-Type)
FIG. 103 FIG. 103: To select rear PTO - Make sure PTO control switch is OFF and then move rear PTO selector lever (2) engage gear set (4) inside rear housing. FIG. 103: To engage PTO - Turn PTO switch, clockwise and then pull up to actuate hydraulic clutch (5) and complete the drive. The indicator light in the warning light strip will come on, showing PTO clutch is engaged. FIG. 103: To disengage PTO - Push PTO switch (1) to release hydraulic clutch (5). When further use of rear PTO is not required, depress clutch pedal and return rear PTO selector lever (2) to neutral.
FIG. 104
FIG. 105: To select mid PTO - Make sure PTO control switch is off and then move PTO selector lever (8) forward to mid PTO position to engage gear set in mid PTO. NOTE: PTO can be engaged / disengaged by control switch (1) independently of main clutch. Reduce engine revolution speed prior to engaging (switching on) and disengaging (switching off) PTO. Always move PTO control switch to OFF before shifting rear or mid PTO selector levers. Rear and mid PTO can be operated separately or together. FIG. 105 59
