OPERATING CONTROLS AND PROCEDURES
low steer pressure condition that causes a related warning LED to light. The buzzer is on the relay panel assembly near the front console.
Hourmeter (Not Shown) The hourmeter is located on the right side of the engine hood, below the air intake filter. The hourmeter is used to register hours of engine operation.
Skylight Wiper (Not Shown) The electrically-operated skylight wiper is installed to remove moisture from the skylight. The single-speed wiper is located on the left side of the skylight frame. The skylight wiper is controlled by a switch on the wiper motor.
Backup Alarm (Not Shown) The backup alarm is an audio system used to warn personnel outside the crane when the crane is backing up. The alarm system is electrical and consists of the backup alarm and its associated wiring. The alarm is connected to the electrical wiring for the transmission reverse solenoids. It is activated when the transmission shifter is in the reverse
position. The backup alarm is installed in the rear outrigger box behind the grill plate.
Data Link and Service Connector (Not Shown) The J1939 data link and service connector is mounted on the right side of the cab near the 12VDC accessory outlet. It is used for troubleshooting electrical system and engine faults and conditions. NOTE:
A laptop computer with appropriate cable and engine or electrical system software are required.
Anemometer (Not Shown) A hand hold anemometer is provided in the cab. It is a wind speed indicator with a compass located on the top. It measures wind speed on a scale from 15 to 70 mph.
Emergency Exit The windshield is considered the Emergency Exit. In an emergency, push out on the windshield and escape through the opening.
