Chapter 7 LUBRICATION GENERAL INFORMATION
LUBRICANTS The chart on this page lists the locations, temperature ranges and recommended types of lubricants to be used when servicing this machine. Also refer to the separate engine manual for additional information regarding recommended engine lubricants, quantities required and grades.
WARNING NEVER lubricate or service this unit when any part of the machine is in motion. ALWAYS exercise the MANDATORY SAFETY SHUTDOWN PROCEDURE (p, 17 SAFETY chapter) before lubricating or servicing this equipment.
NOTE: Refer to “Operator Services” in the Service and Storage chapter of this manual for detailed information regarding periodic checking and replenishing of lubricants.
NOTE: The Maintenance chapter (Chapter 9) in this manual has provisions for recording the dates and hourmeter readings after lubrication or other service has been performed; use those spaces to keep a log for maintaining a current service interval record. Proper routine lubrication is an important factor in preventing excessive part wear and early failure.
Fluids/Lubricants Types and Capacities Component/Application
Type
Quantity
All Grease Fittings
Use No. 2 Lithium Based Grease
As Required
Brake System
Uses Hydraulis System Oil
As Required
Transmission Oil
Use Multi-ATF Dexron III or equivalent
All models: 12.9 L (13.75 gts.)
Hydraulic Reservoir
Use Mobil DTE 15M, or equivalent that contains anti-rust, anti-foam, and anti-oxidation additives. Must conform to ISO VG46/VG32
Reservoir: 113.5 L (30 gls.)
Axle Oil
MobilFluid 424 (recommended) CHS Cenex Qwiklift HTB or equivalent
Capacity: RS9-50, RS10-44, RS10-55, RS12-42 Front Differential: 14.0L (14.8 qts.) Front Planetary: 1.75 L (1.85 qts.) Rear Differential: 13.5 L (14.2 qts.) Rear Planetary: 1.8 L (1.9 qts.) Capacity: RS6-42, RS8-42/44 Front and Rear Differential: 15.0L (15.8 qts.) Front and Rear Planetary: 2.5 L (2.6 qts.) each
Diesel Fuel Diesel Exhaust Fluid (DEF)
Use only ultra low sulfer diesel (ULSD) fuel with a maximum of 15 PPM sulfur content Fuel Tank Capacity: 178 L (47 gls.) specified to EN590 or ASTM D975 Must meet ISO 22241-1 or DIN 70070 stan- DEF Tank Capacity: 19 L (5 gls.) dards
