Installation of a Personnel Work Platform (PWP)
WARNING The PWP must meet ANSI/ITSDF B56.6-2016, Section 8.24. (See page 24 in the Safety chapter for PWP design requirements.) If the PWP being used does not offer means to secure the PWP to the forks and to secure the forks from pivoting, as shown in steps 2 and 3, then an alternate method must be used.
WARNING The machine must not be used to lift or carry personnel, or be fitted with any form of personnel work platform unless fitted with the optional PWP System. If fitted with the PWP System, the Mandatory Work Platform Safety Rules (p. 22) must be followed to at all times while lifting personnel. 1.
Center the forks on the carriage, spaced apart to match the distance required to engage the PWP.
2.
After the forks are fully engaged in the PWP, secure the PWP to the forks. This can be accomplished by means of a retaining pin behind the heel of the forks, as shown.
4.
For machines with a 42-foot or 44-foot boom: Connect the coiled wire from the remote shutdown switch to the connector on the end of the boom. Secure the remote shutdown switch to the PWP using the strap attached to the switch, as shown. Electrical Connection
PWP Remote Shutdown Switch Retaining Pin
3.
Remote Shutdown Switch with Coiled Wire Connector
Secure the forks from pivoting upward in case the PWP is lowered onto an obstruction. This can be accomplished by using the chain supplied with the PWP, to secure the lower portion of the PWP to the bottom of the carriage, as shown below.
5.
For machines with a 50-foot or 55-foot boom: The remote shutdown switch is wireless-operated. Secure the remote shutdown switch to the PWP using the strap attached to the switch, as shown.
Chain
PWP Remote Shutdown Switch
Wireless Remote Shutdown Switch on 50’ and 55’ Models 6.
PRINTED IN U.S.A.
65
Secure the lanyard from the body harness to the PWP or the boom. Each person in the PWP should have a body harness with a lanyard attached to the PWP.
