SAFETY 6. During use, no part of the equipment, load line or load will be within the minimum clearance distance specified by OSHA [10 feet (3.0 m), and more for lines rated over 50 kV] of any energized power line, and any taglines used are non-conductive. 7. In addition, for lift equipment with a rated capacity greater than 2000 lbs. (907 kg), the employer must ensure that: a.) An accessible fire extinguisher is on the forklift; b.) Monthly and annual inspections are performed and documented, and records retained (three months for monthly, one year for annual); c.) Before November 10, 2014, operators must have had the additional training and qualification / certification required by OSHA regulations §1926.1427 and §1926.1430. Note: Refer to the full text of the OSHA crane regulation (29 CFR Part 1926, Subpart CC) for a detailed description of the regulatory requirements. Ü
During transport, the length of the rigging between the attachment and load should be as short as possible to reduce booms height and movement. DO NOT raise the load more than 12 inches (305 mm) above the ground, or raise the boom more than 45 degrees.
Ü
Only lift the load vertically – NEVER drag it horizontally.
Ü
Use multiple pickup points on the load when possible. Use taglines to restrain the load from swinging and rotating.
PRINTED IN U.S.A.
Start, travel, turn and stop SLOWLY to prevent the load from swinging. DO NOT exceed walking speed.
Ü
Inspect rigging before use. Rigging must be in good condition and in the U.S. comply with OSHA regulation §1910.184, “Slings,” or §1926.251, “Rigging equipment for material handling.”
Ü
Rigging equipment attached to the forks must be secured such that it cannot move either sideways or fore and aft. The load center must not exceed 24 inches (610 mm).
Ü
DO NOT lift the load with anyone on the load, rigging or lift equipment, and NEVER lift the load over personnel.
Ü
Beware of the wind, which can cause suspended loads to swing, even with taglines.
Ü
DO NOT attempt to use frame-leveling to compensate for load swing.
Servicing Safety Reminders Ü ALWAYS be aware of and avoid pinch point areas on the machine, such as wheels-to-frame, cylinders-to-frame, boom-attachment-tool-to-frame. Ü NEVER attempt to by-pass the keyswitch to start the engine. ONLY use the jump-starting procedure detailed in the Service and Storage chapter.
DO NOT exceed the rated capacity of the telescopic handler as equipped for handling suspended loads. The weight of the rigging must be included as part of the load.
Ü
Ü
Ü NEVER use your hands to search for hydraulic fluid leaks. Instead use a piece of paper or cardboard. Escaping fluid under pressure can be invisible and can penetrate the skin, causing serious injury. If any fluid is injected into your skin, see a doctor at once. Injected fluid MUST be surgically removed by a doctor familiar with this type of injury or gangrene may result. Ü ALWAYS wear safety glasses with side shields when striking metal against metal. In addition, it is recommended that a softer (chip-resistant) material be used to cushion the blow. Failure to heed could lead to serious injury to the eyes or other parts of the body.
