CHAPTER 11 TRANSPORTING SAFETY CHAIN (Fig. 25) NOTE:
Refer to the Optional Features & Accessories chapter for the Safety Chain and Transport Lighting Kit ordering information.
CAUTION ALWAYS follow state and local regulation regarding use of a safety chain and transport lighting when towing farm equipment on public highways. ONLY a safety chain (NOT an elastic or nylon/plastic tow strap) should be used to retain the connection between the towing and towed machines, in the event of separation of the primary attaching system. BE SURE to check with local law enforcement agencies for your own particular regulations. Unless otherwise prohibited, use a Slowmoving Vehicle Emblem.
Accessories chapter for ordering information. The Safety Chain should be attached to the tractor and Mixer Feeder as shown. When attached in this manner, the safety chain should have the following characteristics: 1.
Chain is sufficiently slack to allow turns and movements of either the tractor or the farm implement, without placing tension on chain.
2.
Chain is of sufficient strength to hold the decoupled implement (and its load) and tow it to the shoulder.
SMV EMBLEM & REFLECTORS (Figs. 26 & 27) The GEHL MF7000 Series Trailer-type Mixer Feeders are provided with a Slow-moving Vehicle Emblem on the back of the Box. Red Reflector Strips are also provided on the back corners of both Fenders and the rear corner of the Discharge Conveyor. An Amber Reflector Strip is provided on the front corner of the Discharge Conveyor.
1
3 1
2 1 – Safety Chain Fastened to Mixer Feeder Drawbar 2 – Locking Hitchpin 3 – Safety Chain & Clevis
Fig. 25
As required or when desired, the Trailer-type Mixer Feeder can be equipped with a Safety Chain for travel on public highways. Refer to the Optional Features &
3
2
1 – Red Reflector Strip 2 – Red Reflector Strip on Fender (Both Sides) 3 – Slow-moving Emblem (SMV) Decal
Fig. 26
35
