Assembly INSTALL WARNING LIGHTS (Model DH4414) Note: Model DH44414 only Refer to 5RP3032326 Light Group Assembly shown in Repair Parts List. (Part # 5RPMAN294P) 1. Attach bolting plates to the ends of the rear gang carrier. 2. Attach the lights to the bolting plates so that the red lens .
faces rearward with the amber to the top visible from both front and rear.
3. Connect the wishbone harness marked left and right to each of the lights. 4. Route the wishbone harness around the frame. 5. Secure the wishbone harness with the clamps provided in the light group assembly. 6. Attach the straight harness to the wishbone harness. 7. Secure the straight harness to the drawbar with a clamp. 8. Store the excess length and the plug in the hose mast.
