Frontier Wheel Off Set Disk Harrow DH4411 DH4414 Assembly & Operating Instruction Manual

Assembly CHECK ALL PARTS ON PACKING LIST For Export Shipment assembly procedure, follow steps 1 through10.

For Domestic Shipment assembly procedure, follow steps 3 through 10.

Note: Use of the parts diagrams and parts listings in the Repair Parts catalog (# 5RPMAN294P) may facilitate assembly of the disk harrow.

STEP 1. ASSEMBLING GANGS For shipping purposes, the bearings, spacers, axle washer, bumper washer, axle nuts and axle nut locks are shipped bundled together.

To assemble the gangs, these following steps should be observed.

Mount disk blades on each axle assembly as shown. The number of disks and spacers will vary for each size gang.

A. Remove the axle nut on the bumper washer end of the shipping assembly. The bumper washer is the one that fits the convex surface of the disk blade.

B. Remove all bearings and spacers on the axle.

This leaves only the bumper washer, an axle nut lock and one axle nut on the axle.

C. Important: Care should be taken to prevent damage to the axle threads as parts are slid off and on the axle.

D. Slide one disk blade down the axle until it contacts the axle washer. Note: The axle washer fits the concave side of the disk blade. Bearings and spacers have concave and convex ends. Curvatures must mate with disks or the gangs will not stay tight and damage will result. Now, slide a bearing onto the axle.
