Frontier Wheel Off Set Disk Harrow DH4411 DH4414 Assembly & Operating Instruction Manual

Operating the Machine HYDRAULIC CONTROL The disk can be raised onto the transport assembly by operating the hydraulic control unit.

Extending the hydraulic cylinder will raise disk and lower the wheels for transporting and turning.

Note: The wheels can be locked in the lowered position for transporting the disk by securing the transport lock to the cylinder rod on the hydraulic cylinder. Consequently, the cylinder cannot retract and damage the disk should hydraulic pressure be lost while transporting.

SCRAPER ADJUSTMENT Each scraper should be adjusted so that it does not come in contact with the disk blade as the blade turns, but be slightly closer at the point so that trash cannot build up between the scraper and the disk blade.
