ASSEMBLY INSTRUCTIONS DEALER SET-UP INSTRUCTIONS The mower is shipped mostly assembled but requires dealer set-up. The Frontier dealer should deliver the mower to the owner completely assembled, lubricated, and adjusted for normal conditions. Recommended torque values for hardware are located on page 61. Complete check lists on page 38 when assembly is complete.
Keep hands and body away from pressurized lines. Use paper or cardboard, not hands or other body parts to check for leaks. Wear safety goggles. Hydraulic fluid under pressure can easily penetrate skin and will cause serious injury or death. Make sure that all operating and service personnel know that if hydraulic fluid penetrates skin, it must be surgically removed as soon as possible by a doctor familiar with this form of injury or gangrene, serious injury, or death will result. CONTA CT A P H YS IC IA N IM M ED IAT E LY IF FLU I D ENTERS SKIN OR EYES. DO NOT DELAY.
Remove hardware
Figure 25. Remove Shipping Hardware 5. Gently lower deck until the deck is supported by the lift chains. 6. Remove 5/8 lock nuts and remove shipping strap from between right and left decks, Figure 26.
Remove 5/8 Lock nut
Make sure spring-activated locking pin or collar slides freely and is seated firmly in tractor PTO spline groove.
Always wear relatively tight and belted clothing to avoid getting caught in moving parts. Wear sturdy, rough-soled work shoes and protective equipment for eyes, hair, hands, hearing, and head; and respirator or filter mask where appropriate.
Figure 26. Remove Shipping Strap (Right Wing)
ATTACH HYDRAULIC HOSES
REMOVE SHIPPING STRAPS 1. Remove front drive from between wing frames. 2. Attach to stub shaft (see trailer assembly). 3. Lift rear deck to take tension off rear lift chains. 4. Remove 3/8 bolts, washers, and nuts from both rear lift chains. See Figure 25. This hardware is for factory shipping purposes only and can be discarded.
34 Assembly
Air in hydraulic systems can cause erratic operation and allows loads or equipment components to drop unexpectedly. When connecting equipment or hoses or performing any hydraulic maintenance, purge any air in hydraulic system by operating all hydraulic functions several times. Do this before p ut t i n g i n t o s e r v i c e o r a l l o w i n g a n y o n e t o approach the equipment.
