Maintenance 5. Replace the knife mounting disc unit onto the spindle. With this step you will reset the timing of the unit. Pay special attention to the orientation of the disc when replacing. (Reference spindle diagrams on pg. 34)
7. Next replace the spacer plate followed by the top cap. Tighten the 6 remaining bolts.
6. Place the large Belleville washer and retaining nut back on the spindle shaft and tighten. Pay special attention to the placement of the washer, place the washer so its cup points towards the bottom; it is designed this way to retain pressure on the assembly.
35
