ASSEMBLY UNCRATING RAKES NOTE: Each crate contains components for two complete machines. Select an area that has adequate room for parts layout and machine assembly. Begin assembly by removing all components from the crate. Lay components out individually for ease of locating during assembly.
INSTALL JACKSTAND 1. Install jackstand (A). Fasten with pin (B) and spring-locking pin. 2. Remove assembly stands from under rear frame.
A—Jackstand B—Pin
INSTALL TONGUE TO REAR FRAME 1. Support rear frame (A) on assembly stands. Make sure frame (A) is positioned so drain hole (B) is toward the bottom. 2. Mark the exact center of rear frame. Use mark for tongue installation. 3. Install tongue (C) and cylinder support (D) in the center of rear frame. Fasten with four M12 x 140 cap screws (E), lock washers, and nuts. A—Rear Frame B—Drain Hole C—Tongue D—Cylinder Support E—M12 x 140 Cap Screws
