Hardware Specifications and Configurations Processor Item
Specification
CPU type
AMD L310/Dual core/1.2G
CPU package
638-pin lidless micro-PGA
Power
•
Features
VCC-CORE: voltage for the future processor will depend on VID0-5 for battery mode and setting via software for adapter mode for the future processor
•
AMD Athlon™ 64 X2 Processor L310
•
Speed: 1.2GHz
•
On-die Cache: 1MB total dedicated L2
•
HT-Link: 16-bit link supporting; speeds up to 800MHz
•
TDP: 13 W
Processor Specifications Item S1g1
CPU Speed TBC
Mfg Tech
Cores 2
TBC
Cache Size TBC
Package TBC
Core Voltage TBC
Acer P/N TBC
CPU Fan True Value Table CPU Temperature (Celsius)
Fan Speed (RPM)
SPL Spec (dBA)
80
5500
36
70
5000
34
60
4500
31
50
4000
28
Throttling 50%: On= 85°C; OFF=95°C OS shut down at 95°C; H/W shut down at 87°C North Bridge Specifications Item
14
Specification
Chipset
RS780MN
Package
528-Pin FCBGA Package (21 x 21 mm)
Power
+1.1V, +1.2V, +1.8V, +3V, +NB_CORE
Chapter 1
