2.
Turn the CPU lock to the locked position.
Replacing the Thermal Module IMPORTANT: Ensure all heat pads are in place before replacing the Thermal Module. The following TIM material and dimensions (mm) are approved for use: CPU TIM PSX-D 18.3*12.3mm
Vram TIM T-Flex-320 13*9*05mm 1.
102
PCHNB TIM FSL-BS 9.5*9.5*1mm
Remove all traces of thermal grease or pad adhesive from the CPU and thermal module using a lint-free cloth or cotton swab and Isopropyl Alcohol, Acetone, or other approved cleaning agent.
Chapter 3
