Functional Description – Keypad Working mode
Vibration, MAN/AUTO
Working lights
Rotating beacon (Option)
Sprinkler Timer Sprinkler MAN/AUTO
Engine speed selector (Not applicable)
Horn
Symbol
Designation Work mode
Vibration MAN/Auto
Function
LED
LED color
LED OFF → Transport mode
-
LED LEFT → Working mode, vibration
Red
LED LEFT → MAN LED RIGHT → AUTO
Red
Turns on the working lights of canopy. Working lights
Sprinkler Manual/Auto
Sprinkler Timer
LED OFF
-
LED LEFT → Working lights, ON
Red
LED LEFT → Sprinkler manual
Red
LED RIGHT → Sprinkler auto
Red
LED LEFT → Sprinkler spray low
Red
LED CENTER → Sprinkler spray medium LED RIGHT → Sprinkler spray high
Engine speed selector
Not Applicable this machine
Rotating beacon (Option)
LED LEFT → Beacon ON
Operation Controls
Red Red
Yellow
26
