4. Running-in period
2. Running-in services Running-in service is to be carried out after operating the dump truck the first 8, 100 and 500 hours. These services are most important for running in a new dump truck. This is the owner’s responsibility.
2.1
First 8 hours: 1. Wheel nuts. • Torque setting:
Check tightening of nuts. 450 Nm. Spanner: 30 mm (from serial no. 513001 and up to 513079) Spanner: 32 mm (from serial no. 513080 and up)
2. Lubricating.
Grease all lubricating points.
3. Battery:
Checking electrolyte level in the batteries, see 40 hours/weekly service, item 1.1 Checking battery charge, see 1000 hours service, item 2.3
4. V-belt:
Checking V-belts condition, see 500 hours service, item 1.4
5. Carry on with the normal 8 hours service, listed in chapter 7, maintenance. Since these points are important for the dump truck to work satisfactorily right from the start they are also listed below. All items below refer to 8 hours / daily service in chapter 7. • Walk around check .............................................. item 1.1 • Check operator seat ............................................ item 1.2 • General condition check - look for leakages, ...... item 2.1 • Check oil level, engine ......................................... item 2.2 • Check coolant level .............................................. item 2.3 Coolant should be filled up when the engine is stopped after first stop, see 2000 hours service, item 1.3 check the coolant. • Check fuel level ................................................... item 2.4 • Function check of the centrifugal cleaner, ........... after first operation ............................................... item 2.5 • Drain air tanks, after first operation ..................... item 2.6 • Check oil level, transmission ............................... item 3.1 • Check oil level, hydraulic system ........................ item 4.1 • Check brake fluid levels ....................................... item 5.1 • Check parking brake capacity, ............................ item 7.1 • Check main brake capacity .................................. item 8.1 • Check main brakes function, ............................... item 8.2 • Check engine brake function ............................... item 9.1 • Check retarder brake function ............................. item 10.1 • Check steering function ....................................... item 11.1
2.2
First 100 hours: 1. Change transmission oil.
20*
See 1000 hours service, item 4.1.
2. Replace transmission filter. 21*
See 1000 hours service, item 4.1.
3. Clean strainer.
22*
See 1000 hours service, item 4.1.
4. Replace hydraulic filter.
43*
See 2000 hours service, item 2.3.
5. Retorque window wiper spindle nuts. • Torque setting: 35 Nm (M10), 18 Nm (M8) 6. Lubricating. Grease all lubricating points.
* Numbers refers to position on lubrication schedule, chapter 6 82
