500 Hours Service
Quick drain plug
1.Engine
1.1.Change oil 1*
If the dump truck is used for particulary demanding operation, especially in a dusty environment or if the deposits in the centrifugal cleaner are thicker than 20 mm: Change oil more often.
1.Remove the oil pan drain plug and drain the oil when the engine is warm.
Access through the rear drain hole in engine belly plate. •If a quick drain plug is fitted: Remove the cap on the drain plug, install the draining hose (tool kit) and drain the oil. 2.Clean magnet on plug. 3.Reinstall the plug when all oil is drained. •Plug torque: 80 Nm. •If quick drain plug is fitted: Remove the draining hose and reinstall the cap. 4.Reinstall the cover for rear drain hole in engine belly plate. 5.Fill oil through filler (2). Do not overfill! 6.Check oil level on dip stick (1).
CAUTION
The oil may be hot! Wear protective gloves and eye protection.
1.2.Clean centrifugal cleaner 2* (at the same time as oil change, item 1.1)
See next page about how to clean the centrifugal cleaner.
1.Unscrew the nut and remove cover.
CAUTION
Open the cover with care. The oil and inner parts may be hot!
2.Lift out the rotor assembly and loosen the nut for the rotor cover three turns.
3. If the nut sticks:
Secure the nut, absolutely not the rotor, in a vice and turn the rotor three turns by hand or using a screwdriver.
4.Gently tap the nut with the hand or with a plastic hammer to separate the rotor from bottom plate.
5.Undo the nut and remove the rotor cover.
6.Carefully prise the strainer loose from the bottom plate.
7.Scrape off the deposits from the inside of rotor cover. •If there are no deposits, this shows that the cleaner is not working. •Clean more frequently if deposits are thicker than 20 mm.
8.Clean all parts in diesel fuel.
9.Place the O-ring in the rotor cover. •The o-ring must be not be damaged. Change if necessary.
10.Assemble the rotor.
11.Tighten rotor nut firmly by hand.
12.Reinstall the rotor. •Check that it rotates easily.
13.Check that the O-ring in the cover is not damaged.
Hard or damaged O-ring must be replaced. 14.Tighten cover firmly by hand. 15.If the nut is tightened too hard (for instance by using tools), the cover, nut or rotor shaft may be damaged! 16.Replace damaged parts!
17.Function check
The rotor rotates very fast, and will normally carry on rotating after the engine is stopped. a.Stop the engine when it is warm. b.Listen for spinning sound from rotor, or feel if cleaner housing vibrates. c.The rotor normally rotates 30 - 60 seconds after the engine has stopped. d.If not, dismantle and check the cleaner.
1.3.Replace turbo filter 3* (at the same time as oil change, item 1.1)
1.Remove the old filter and discard it according to enviromental requirements. 2.Oil the rubber gasket on the new genuine filter. 3.Fit the new genuine filter. 4.Tighten the filter by hand as tight as possible. 5.Start the engine and check for leaks. If the deposits in the centrifugal cleaner exceed 20 mm, the turbo filter must be changed more often, at the same time as cleaning the centrifugal filter and changing the oil.
NOTE
• Never use tools to tighten the filter. It can be damaged and the circulation obstructed! • Use only genuine filter!
1.4.Check V-belts' condition
•Checking of V-belts' condition shall also be carried out after the first 8 hours of operation. •Stop the engine to inspect the V-belts. •Change the belts if damaged or worn (always replace both belts at the same time). •Correct deflection of the V-belts is approx. 10 mm. •Adjust tension if necessary: 1.Loosen bolt 1. 2.Adjust for correct tension with bolt 2. • Do not overtighten the belts!
2. Transmission
2.1.Run the AEB-Tester
AEB = Automatic Filling Parameter Adjustment
To optimize the transmission, run the AEB-Tester. 1.The transmission control unit is located under the left hand side dashboard panel. 2.Follow the procedure described in the table below. The gear display will show the AEB's actions. ("Display message" in the table).
AEB = Automatic Filling Parameter Adjustment TCU = Transmission Control Unit
How to run the AEB-Tester Display message Remarks
1 Warm up the transmission oil, the oil must have a temperature at 70 - 80OC Normal operating messages
2 - Move the gear selector to Neutral position. - Engage the parking brake 3 Turn OFF the starter switch 4 Plug the AEB-Tester into the diagnostic contact no. 607 5 Start the engine "PL" TCU must recognize "PL" for at least 2 sec. before you can press the button.
6 Set engine speed to low idle rpm "PL" if starts condidtions are OK
7 Press button on the AEB Tester"ST" if starts conditions are OK The button must not be released before TCU has started the AEB or quit with an error code.
8 Keep the button depressed until the AEB has started "K1" …… (Information about the AEB state)
9 Wait until AEB is finished "OK" (AEB has been successful)
10 Turn OFF the starter switch and unplug the AEB-Tester 11 Remount the dashboard panel TCU has started the AEB and goes to adjusting K1, K2, …, KR. (Button may be released).
NOTE
• If the oil temperature is too low or too high, following message will apear on the gear display:
T or T . Adjust the oil temperature and try again. • If there is a malfunction, turn the starter switch off and start the engine again. • The AEB will not start if any error codes are shown on the gear display, except error code "F6"
1 2
3. Drive line
3.1.Check oil levels
Measurements must be carried out when dump truck is parked on a horizontal ground. Check that oil level is near the bottom edge of the plugs. Refill with oil if level is too low. If the dump truck tandem housing is angled, the reading will be incorrect.
CAUTION
Be aware of possible internal pressure when the oil is hot!
1. Front differential 30*
Use a hexagonal key (1) to unscrew the upper filling/level plug (2). •Plug torque: 80 Nm.
2. Rear differential 31*
Use a hexagonal key (1) to unscrew the filling/level plug (2) at the rear of housing. •Plug torque: 80 Nm.
2
1 3. Tandem housings 32*
Use a hexagonal key (1) to unscrew the level plugs (2) on the inside of the housings. •Plug torque: 80 Nm.
4. Front reduction gears 33*
Turn the hubs until level indicator is horizontal (1). Use a hexagonal key (2) to unscrew the plugs (3). •Plug torque: 80 Nm.
Service brakes
Parking brake
1 1
2
4.Brake system
4.1.Check lining thickness
•Checking of brake lining thickness shall also be carried out after the first 250 hours of operation. 1.Service brakes: Check brake linings. Brake linings should be changed before the thickness of the linings on the most worn areas reaches 3,5 mm.
•How often the brake linings have to be checked/replaced depends on how much the brakes are used and/or application. After checking the brake linings for the first 250 hours, consider whether or not the brake linings should be checked more often, based on lining wear. •Also if there often (monthly) have to be filled up with brake fluid, the brake linings must be checked and if necessary replaced (see 8 hours/daily service).
If the linings have to be replaced, be aware that overflow of brake fluid in the reservoirs can occur.
To avoid this, open the bleeder plug before the old lining is pushed back to give space for the new one. 2.Parking brake:
Lift body and apply the body support (1). Check thickness of linings through inspection hole (2) on top of the caliper.
Change when approaching limit. •After replacement perform adjustment, see next page.
Standard lining thickness:Service brakes: 22.0 mm Parking brake: 18.0 mm Min. thickness: Service brakes: 3.5 mm. Parking brake: 3.5 mm.
CAUTION
This applies to normal driving. For rough operating conditions with much brakingand/or driving in water, the brake linings should be checked more often!
1
1
2
4.2.How to adjust the parking brake.
To be performed after replacement of parking brake linings. 1.Apply the parking brake and make sure that the system pressure is at normal operating pressure which is between 6.8 - 7.8 bare (see air pressure gauge, in chapter 3). 2.Lift the body. 3.Apply the body support (1) (see also safety instructions, chapter 2). 4.Stop the engine. 5.Secure the dump truck with wheel chocks (see also safety instructions, chapter 2) 6.Release the parking brake. 7.Turn the adjusting screw anticlockwise until a total clearance of 1.5 mm (2) is obtained between outer lining and disk. (Measure at centre of lining when sliding caliper max. outwards.) 8.Place a wrench on the adjusting screw (3), and apply the parking brake in the cab several times. Look out of the rear window to follow the wrench and when no further rotation on the adjusting screw is observed, the brake is correctly adjusted. 9.Remove the wrench and check function and effect.
5. Wheels
5.1 Check wheel nuts torque.
Torque setting 450 Nm. Wheel spanner in the tool box.
6.Air conditioner system
6.1.Test operation
1.Start the engine. 2.Press down the air conditioner switch, set the thermostat for air conditioner to maximum cooling, and the fan switch to position 3 (see also chapter 3), and open all nozzles. 3.Check that the indicator light illuminates. •If the indicator light does not illuminate: •Check whether the indicator bulb or fuse is burnt out, if yes, replace the bulb or fuse and go on to item 4. •If neither the bulb nor fuse is burnt out, there can be a failure: CONTACT YOUR LOCAL MOXY DEALER.
4.Check that the temperature in the cab decreases. •If the temperature does not decrease, there can be a failure or too little refrigerant in the system:
CONTACT YOUR LOCAL MOXY DEALER
WARNING
• If the air conditioning system does not work properly, contact your Moxy Dealer in all cases!
• Always use safety glasses or goggles, gloves, boiler suit and protective footwear when inspecting, servicing and repairing the air conditioning system.
• Refrigerant R134a has a property that can cause frostbite if it comes into contact with bare skin or eyes.
• Always work on the air conditioning system in well ventilated places.
• The system contains refrigerant R134a under pressure. Repair and refilling of the refrigerant circuit must only be done by accredited personnel.
• Dispose of waste oil/fluids in an enviromentally friendly manner!
• High concentration of the refrigerant in gaseous form can cause drowsiness, headache, dizziness and at worst unconciousness. Very high concentration of the gas can even cause cardiac insufficiency.
Do not smoke when servicing the air conditioning system!
• Be careful with all hoses connected to the air conditioning system. There is always a certain overpressure in the system. Therefore, never undo hoses or the filler opening on the compressor except during repairs to the system.
• If there is any suspicion of leakage, the system must not be filled up - leave the leakage site and contact your Moxy Dealer for repairs.
• Get your Moxy Dealer to check the air conditioning system once per year.
• See also chapter 2, safety instructions
7.Automatic central lubrication
7.1.Refill the reservoir, the reservoir must be refilled if the indicator light flashes for 2 minutes (0.5s on/0.5s off) at the beginning of each cycle.
1.Remove the dust cap from the filler coupling. 2.Carefully clean the filler coupling and the coupling on the filler hose.
3.Fit the filler hose on the filler coupling. 4.Fill the reservoir up to the maximum level indicated on the reservoir.
5.Remove the filler hose and fit the dust cap.
7.2.Check the system
•Check the pump for damage and leakage. •Check the grease lines for damage and leakage. •Check, if possible, the condition of the grease points the system serves. Sufficient fresh grease should be present. •Check the operation of the system. Perform a cycle test (see chapter 3 for how to perform a cycle test). Note that every time you perform a cycle test, grease is supplied to the grease points. •Clean the pump-unit and its surroundings.
NOTE
• If you use a high-pressure air or water gun to clean the dump truck, do not spray directly onto the pump unit. Water or dirt might enter the pump-unit through the de-aerating openings.
• Even if the automatic central lubrication is installed, do not forget that there are still some greasing points that must be greased by hand, these are the doors and fender hatches.
8.Lubrication
Grease lubrication points until pure grease is forced out of the components.
8.1.Doors and fender hatches, 8 lubricators 57*
There are 2 lubricators on each door and hatch (one per hinge)
8.2. Suspension legs, 4 lubricators 59*
The lubricators are located on the distribution block (fitted on rear, right side of the front frame).
