2. Safety Instructions
20. Body support 1
Always secure the raised body with the body support before service/inspection and other work underneath the body. The body support device is intended for empty body only! • Engagement of the support device: 1. Raise the body. 2. Make sure that the parking brake is on (locked) before leaving the cab. 3. Lift the body support in top position (pos 1). 4. Slowly lower the body towards the support device until firmly positioned. 5. Return the tip control lever to hold position. 6. Stop the engine and remove the starter switch key. • Disengagement of the support device: 1. Start the engine. 2. Push the tipping system switch (see chapter 3, operating controls) and keep it depressed while the body is lifted slightly. 3. Release the switch when the body is off the body support. 4. Return the tip control lever to hold position. 5. Make sure that the parking brake is on (locked) before leaving the cab. 6. Lower the body support. 7. Lower the body.
DANGER It is hazardous to work/stand underneath the body without applying the body support device! Do not operate the dump truck with a raised and secured body!
26
Operating & Maintenance Manual
