7. Maintenance
500 Hours Service Maintenance to be performed every 500th hour of operation.
1. Engine 1.1. Change oil 1*
If the dump truck is used for particulary demanding operation, especially in a dusty environment or if the deposits in the centrifugal cleaner are thicker than 20 mm: Change oil more often. Quick drain plug
1
2
1. Remove the oil pan drain plug and drain the oil when the engine is warm. Access through the rear drain hole in engine belly plate. • If a quick drain plug is fitted: Remove the cap on the drain plug, install the draining hose (tool kit) and drain the oil. 2. Clean magnet on plug. 3. Reinstall the plug when all oil is drained. • Plug torque: 80 Nm. • If quick drain plug is fitted: Remove the draining hose and reinstall the cap. 4. Reinstall the cover for rear drain hole in engine belly plate. 5. Fill oil through filler (2). Do not overfill! 6. Check oil level on dip stick (1).
CAUTION The oil may be hot! Wear protective gloves and eye protection.
1.2. Clean centrifugal cleaner 2* (at the same time as oil change, item 1.1) See next page about how to clean the centrifugal cleaner.
* Numbers refer to positions on the lubrication schedule, chapter 6 Operating & Maintenance Manual
139
