5 - ASSEMBLY
5 - ASSEMBLY Front loader arm hydraulic system
Ride control Boom hydraulic line removal 1. On the main control valve, locate the hose (A) (marked with grey tie, see arrow) and the hose (B) (marked with brown tie, see arrow). 2. Remove the hose (A) from the fitting (C) and the hose (B) from the 90° elbow (D). 3. Remove the fitting (C) from the port A2 of the main control valve and the 90° elbow (D) from the port B2 of the main control valve.
LEIL19CWL0339AA
1
LEIL19CWL0341AA
2
4. On the rear frame, remove the bolts (G), the washers (H), and the nuts (L) to separate the clamps (E). 5. Loosen the bolts (M) to move the plates (F) and facilitate the removal of the hose (A) and the hose (B) (see also Figure 1) from the clamps (E).
8 EN
