3 - GENERAL INFORMATION
3 - GENERAL INFORMATION###_1_### Basic instructions READ THE FULL INSTRUCTION BEFORE STARTING THE INSTALLATION!
• References to “left” and “right” are determined from the rear, facing in the direction of travel of the machine during operation. • To access the different components, see the operator’s manual of the machine. • Callout references: - Numeric callout references (example: (1)), refers to item (1) in the kit content list. - Letter callout references (example: (A)), refers to the component on the unit, not to an item in the kit content list. • Use ANTIFRET to minimize fretting corrosion between two metal surfaces. Fretting corrosion is caused by very slight oscillations or by vibrations. This may lead to serious damage in bearings and other machine parts and can make dismounting almost impossible. • Always tighten the hardware unless instructed not to tighten in the step involved. • Tighten the hardware to the standard torque specifications unless otherwise instructed. • Make sure to use the hardware specified in tapped holes. Install a metric bolt in a metric thread or an inch bolt in an inch thread, otherwise you will damage the threads! • Install flat washers over all slotted holes unless truss-head or carriage bolts are used. Install a lock washer on all the bolts unless a jam nut or a lock nut is specified. • Install special hardened washers where specified.
6 EN
