5 - ASSEMBLY
Electrical component installation 34. On the left-hand side of the rear frame, locate the connector X-090A (S) and the connector X-090B (R) of the frame harness (T). 35. Remove the plugs and connect the connector X-090A (S) and the connector X-090B (R) to the ride control solenoid valves as shown in Figure 27. 36. Secure the wire of the connector (R) to the hose (13). Use the cable tie (19). 37. Secure the wire of the connector (S) to the hose (14). Use the cable tie (19). 38. Secure the frame harness (T) to the greasing lines. Use the cable ties (19).
LEIL19CWL0343AA
27
LEIL19CWL0346AA
28
LEIL19CWL0344AA
29
LEIL19CWL0345AA
30
39. Inside the cab, on the right-hand console, remove the switch panel (U).
40. Remove the plug and install the rocker switch (18). 41. Locate the connector X-032 (X) of the main cab harness (Y). 42. Connect the connector X-032 (X) to the rocker switch (18).
43. Reinstall the switch panel (U).
