4 - ASSEMBLY
5. Set the hook link (17) in position. 6. Align the upper holes in the hook link (17) and the mounting holes of the machine. 7. Install the upper pin (S), the shims (R), and the snap rings (Q). 8. Align the lower holes in the hook link (17) and the mounting holes of the machine. 9. Install the lower pin (O), the shims (N), and the snap rings (M).
RAIL16TLB0362BA
21
RAIL14TLB0878BA
22
RAIL14TLB0879BA
23
Electric harness install 1. Inside the cab remove the plug (T) on the front left-hand instrument panel (U). 2. Paying attention to the electric connections, partially lift the front left-hand instrument panel (U) to make the lower side accessible.
3. Remove the screws (W) securing the side instrument cluster (X). NOTICE: Care must be used when pulling the panel away from the cluster so that there is no damage to the wire harnesses.
13 EN
